1.5 T mainstream load capacity with a boutique narrow body design. Vehicle width is only 1128 mm, with a minimum turning radius of 1329 mm, ensuring smooth operation in narrow passages.
Supports identification of pallets of multiple specifications and colors, as well as material racks and cages. Adaptive high-precision identification from multiple angles ensures stable pick-up and delivery.
Customizable fork heights (2344/2924/3244 mm) and widths (550/600/680 mm). Supports multi-layer stacking, various laser navigation options, and 3D obstacle avoidance.
Equipped with a 24 V / 212 Ah battery providing up to 10 hours of operation. Supports quick battery replacement within 3 minutes for continuous workflow.
3D obstacle avoidance camera scans items within 0.2m to 5m, measuring object depth data for 360° enhanced safety protection.
The SFL-CDD15 redefines high-density vertical logistics in constrained spaces, combining power and precision for modern warehouses.
| Parameter Item | SFL-CDD15 Details | |
|---|---|---|
| Basic Parameters | ||
| Product Name | Laser SLAM stack-height smart forklift | |
| Navigation Method | Laser SLAM | |
| Rated Load Capacity | 1500 kg | |
| Standard Lifting Height | 2344 mm / 3244 mm | |
| Vehicle Dimensions (LxWxH) | 1730 x 1128 x 1964 mm | |
| Minimum Turning Radius | 1329 mm | |
| Performance & Battery | ||
| Driving Speed (Full/Empty) | 1.5 / 1.8 m/s | |
| Navigation Accuracy | ±10 mm (Position), ±0.5° (Angle) | |
| Battery Specifications | 24 V / 212 Ah (Lithium iron phosphate) | |
| Comprehensive Endurance | 10 h | |
| Charging Time (10%-80%) | 2 h | |
| Functional Configuration | ||
| 3D Obstacle Avoidance | Optional (○) | |
| Stack/Cage Recognition | Optional (○) | |
| 360° Laser Protection | Standard (●) | |
| Emergency Stop / Audio-Optical | Standard (●) | |
